A8 MINI 4K Zoom Camera with 3-Axis Gimbal

In stock(9)
Sku:  R2210251
Weight:  95g
Special Price $229.00 Regular Price $299.00
Reward Points With this product, you earn 299 loyalty points.
  • AI Smart Identify Tracking
  • 1/1.7 Inch Sony CMOS
  • 4K Ultra HD Photo & Video Recording
  • 6X Digital Zoom
  • Upside Down Mode
  • Starlight Night Vision Camera

The shipping costs on the website are for reference only. For actual shipping costs, please contact our sales.

4K AI camera 4K AI camera 4K AI camera 4K AI camera 4K AI camera 4K AI camera starlight night version camera UGV camera PTZ camera PTZ camera PTZ camera

More Information
Specification

A8 mini

Technical Specifications



Overall

Model: A8 mini

Video Output Port: Ethernet, HDMI, CVBS (AV)

Control Signal Input Port: S.Bus / UART / UDP

Control Signal Output Port: S.Bus

Working Voltage: 11 ~ 25.2 V

Power Consumption: Summit 12 W

Working Temperature: -10 ~ 50 ℃

Dimension: 55*55*70 mm

Weight: Approx. 95 g



Gimbal

Angular Vibration Range: ±0.01°

Controllable Pitch Angle: -135° ~ +45°

Controllable Yaw Angle: -160° ~ +160°

Controllable Roll Angle: -30° ~ +30°



Camera

Lens: 6X Digital

Focal Length: 21 mm

Image Sensor: Sony 1/1.7-inch, 8 MP effective resolution

Aperture: F2.8

FOV: 93°

TF Recording Resolution:

  • 4K (4096 x 2160) @ 25 fps
  • 2K (2560 x 1440) @ 30 fps
  • 1080p (1920 x 1080) @ 30 fps
  • 720p (1280 x 720) @ 30 fps

Supported File System: FAT32 (exFAT will be supported later by firmware update)

Photography File Format: JPG

Video File Format: MP4

Supported MicroSD Cards: MicroSD Class10, max 128 GB

White Balance: Auto
